Description

The Power Pack for AUDX is an essential kit designed for comprehensive battery monitoring and connectivity in advanced power systems. This pack includes a highly versatile SmartShunt battery monitor and two 1.5m red cables, each equipped with a fuse, providing a robust solution for managing your power needs.

SmartShunt Battery Monitor

The SmartShunt battery monitor is a pivotal component of this kit, offering precise monitoring capabilities. It features an IP21 rating, necessitating installation in a dry location to ensure optimal performance. The monitor is designed for secure mounting with two 5.5 mm holes in its base, providing stability and ease of installation.

Connection Terminals

• LOAD MINUS
• BATTERY MINUS
• VE.Direct Terminal
• Auxiliary (Aux) Terminal
• Vbatt+ Terminal

For the 300A model, the terminals are equipped with M8 bolts, while other models use M10 bolts, ensuring compatibility with various setups.

Installation Overview

The installation process is straightforward:

• Connect the negative battery terminal to BATTERY MINUS.
• Connect the system negative to LOAD MINUS.
• Use the red cable with a fuse to connect Vbatt+ to the battery positive terminal.

This configuration facilitates seamless integration into your existing power system.

Auxiliary Connections

The SmartShunt monitor supports auxiliary connections, allowing you to monitor a second battery, battery bank midpoint, or battery temperature. Note that monitoring battery temperature requires an optional temperature sensor.

Device Connectivity

Connectivity is a standout feature, with the ability to link to GX devices such as the Cerbo GX via VE.Direct or USB. This connection enables comprehensive parameter readout, enhancing your system's monitoring capabilities.

Configuration

Configuration is made simple through the VictronConnect app, where the SmartShunt can be set up as a DC meter, tailoring its functionality to meet your specific requirements.

Use Case

Ideal for those seeking advanced integration with power systems, the Power Pack for AUDX provides reliable monitoring and connectivity solutions, ensuring your power management is both efficient and effective.
